Huawei CloudEngine CE5800 Series Data Center Switch
-
Model:
Huawei Data Center Switches -
Detail:
Huawei CloudEngine CE5800 series (CE5800 for short) switches are next-generation, high-density Gigabit Ethernet switches designed for data centers and high-end campus networks. The hardware has an advanced architectural design with the industry’s highest density of GE access ports. The CE5800 is also the first Gigabit Ethernet access switch to provide 40 GE uplink ports. -
Price:
$10.00
- Free Technical Support
- Product Quality Protection
- On-time Shipment
- +86 755 8215 3862
- leo@uonel.com
- ywx39894
CloudEngine 5800 Series Data Center Switches
Huawei CloudEngine CE5800 series (CE5800 for short) switches are next-generation, high-density Gigabit Ethernet switches designed for data centers and high-end campus networks. The hardware has an advanced architectural design with the industry’s highest density of GE access ports. The CE5800 is also the first Gigabit Ethernet access switch to provide 40 GE uplink ports.
Using the Huawei VRP8 software platform, CE5800 switches support Transparent Interconnection of Lots of Links (TRILL) and have a high stacking capability (up to 16-member switches in a stack system). In addition, the airflow direction (front-to-back or back-to-front) can be changed. CE5800 switches can work with CE12800 switches to build an elastic, virtualized, high-quality fabric that meets the requirements of cloud-computing data centers.
CE5800 switches provide high-density GE access to help enterprises build a scalable data center network platform for cloud computing. They can also be used as aggregation or access switches for enterprise campus networks.
The CE5800 comes in six models.
| Model and appearance | Description |
|---|---|
CE5855-48T4S2Q-EI |
48 x GE BASE-T ports 4 x 10 GE SFP+ ports 2 x 40 GE QSFP+ ports |
CE5855-24T4S2Q-EI |
24 x GE BASE-T ports 4 x 10 GE SFP+ ports 2 x 40 GE QSFP+ ports |
CE5850-48T4S2Q-HI |
48 x GE BASE-T ports 4 x 10 GE SFP+ ports 2 x 40 GE QSFP+ ports |
CE5850-48T4S2Q-EI |
48 x GE BASE-T ports 4 x 10 GE SFP+ ports 2 x 40 GE QSFP+ ports |
CE5810-48T4S-EI |
48 x GE BASE-T ports 4 x 10 GE SFP+ ports |
CE5810-24T4S-EI |
24 x GE BASE-T ports 4 x 10 GE SFP+ ports |
CE5850-HI-B00 |
CE5850-48T4S2Q-HI Switch (2 x 150W AC Power Module, 2 x Fan Box, port side exhaust) | |
CE5850-EI-B00 |
CE5850-48T4S2Q-EI Switch (2 x 150W AC Power Module, 2 x Fan Box, port side exhaust) | |
CE5810-EI-B00 |
CE5810-48T4S-EI Switch (2 x 150W AC Power Module, 2 x Fan Box, port side exhaust) | |
CE5810-EI-B01 |
CE5810-24T4S-EI Switch (2 x 150W AC Power Module, 2 x Fan Box, port side exhaust) | |
CE5810-EI-B11 |
CE5810-EI Bundle 11 (CE5810-24T4S-EI mainframe, 4 x SFP-10G-USR, Without Fan and Power Module) | |
CE5810-EI-B10 |
CE5810-EI Bundle 10 (CE5810-48T4S-EI mainframe, 8 x SFP-10G-USR, Without Fan and Power Module) | |
CE5855-48T4S2Q-EI |
CE5855-48T4S2Q-EI Switch (48-port GE RJ45, 4-port 10 GE SFP+, 2-port 40G QSFP+, without Fan and Power Module) | |
CE5855-24T4S2Q-EI |
CE5855-24T4S2Q-EI Switch (24-port GE RJ45, 4-port 10 GE SFP+, 2-port 40G QSFP+, without Fan and Power Module) | |
CE5850-48T4S2Q-HI |
CE5850-48T4S2Q-HI Switch (48-port GE RJ45, 4-port 10 GE SFP+, 2-port 40G QSFP+, without Fan and Power Module) | |
CE5850-48T4S2Q-EI |
CE5850-48T4S2Q-EI Switch (48-port GE RJ45, 4-port 10 GE SFP+, 2-port 40G QSFP+, without Fan and Power Module) | |
CE5810-48T4S-EI |
CE5810-48T4S-EI Switch (48-port GE RJ45, 4-port 10 GE SFP+, without Fan and Power Module) | |
CE5810-24T4S-EI |
CE5810-24T4S-EI Switch (24-port GE RJ45, 4-port 10 GE SFP+, without Fan and Power Module) | |
