Processors
|
2 or 4 Intel® Xeon® Scalable Processors of up to 205W
|
|
Memory
|
32 DDR4 DIMM slots, up to 2,666 MT/s
|
|
Internal Storage
|
Supports hot-swappable hard drives and the following configuration options:
- 8 x 2.5-inch SAS/SATA HDDs on the front
- 25 x 2.5-inch SAS/SATA HDDs on the front
- 8 x 2.5-inch NVMe SSDs and 16 x 2.5-inch SAS/SATA HDDs on the front (see note 1)
Flash storage:
2 M.2 SSDs (see note 2)
|
|
RAID Support
|
Supports RAID 0, 1, 5, 6, 10, 50, or 60; supports a supercapacitor for cache power-off protection
Supports functions such as RAID state transition and RAID configuration memory
|
|
Network Ports
|
2 x 10 GE + 2 x GE LOM ports
|
|
PCIe Expansion
|
- Up to 9 PCIe slots, 3 of which are built-in card slots and the other 6 external card slots:
− 3 x8 slots for 3 HHHL PCIe 3.0 x16 standard cards
− 1 x8 slot for 1 FHHL PCIe 3.0 x16 standard card
− 5 x8 slots for 5 HHHL PCIe 3.0 x8 standard cards
- The PCIe expansion slots fully support Huawei proprietary PCIe SSD cards, which bolster I/O performance for applications such as searching, caching, and download services
|
|
Fan Modules
|
4 hot-swappable fan modules, providing protection against single-fan failures
|
|
Power Supply Units
|
2 hot-swappable PSUs, with support for redundancy. The PSUs support the following rated power (see note 3):
1,500W AC Platinum PSUs
1,000W (100V to 127V AC input, does not support 1+1 redundancy)
1,500W (200V to 240V AC input)
1,500W (190V to 300V DC input)
|
| Management |
Based on the Huawei iBMC chip, provides comprehensive management features such as fault diagnosis, automated O&M, and hardware security hardening; supports mainstream standard interfaces such as Redfish, SNMP, and IPMI 2.0, facilitating integration with third-party management software; provides remote management interfaces based on HTML5 and VNC KVM; supports features such as Smart Provisioning and Agentless to simplify management.
Optionally configured with Huawei eSight management software; provides advanced management features such as stateless computing, batch OS deployment, and automated firmware upgrade, enabling smart and automated entire-lifecycle management. |
|
Operating Temperature
|
5°C to 45°C (41°F to 113°F), compliant with ASHRAE Classes A3 and A4
|
| Special Notices |
Note 1: The 8-NVMe + 16-SAS/SATA drive model is planned for release in December 2017
Note 2: The 2-M.2 SSD feature is planned for release in December 2017
Note 3: The 2,000W PSU is planned for release in 2018 |
