Huawei AP6610DN-AGN Access Points
-
Model:
Huawei AP6610DN-AGN Access Points -
Detail:
High-speed, reliable wireless access services at 600 Mbit/s (2.4 GHz and 5 GHz radios); 2 x 2 MIMO; 802.11a/b/g/n compatibility -
Price:
$520.00
- Free Technical Support
- Product Quality Protection
- On-time Shipment
- +86 755 8215 3862
- leo@uonel.com
- ywx39894
Share:
Overview
High-speed, reliable wireless access services at 600 Mbit/s (2.4 GHz and 5 GHz radios); 2 x 2 MIMO; 802.11a/b/g/n compatibility
1. SFP: Optical port
2. ETH: 10M/100M/1,000M port that connects to the Ethernet
3. Default button: Restores the factory settings if you remove the screw and hold down the button inside the hole for more than 3 seconds
4. Power input interface
5. Ground port: Connects to a ground cable
6. 2.4 GHz antenna port
7. 5 GHz antenna port
Specifications
|
Specifications
|
AP6510DN-AGN
|
AP6610DN-AGN
|
|
Dimensions (H x W x D)
|
255 mm x 255 mm x 83 mm
|
255 mm x 255 mm x 83 mm
|
|
Power Input
|
PoE: in compliance with IEEE 802.3at
|
AC: 90V to 264V |
|
Maximum Power Consumption
|
25.5W
|
30W
|
|
Operating Temperature
|
−40°C to 60°C
|
−40°C to 60°C
|
|
Antenna Type
|
Dual-polarization antenna or common outdoor antenna
|
Dual-polarization antenna or common outdoor antenna
|
|
Maximum Number of Users
|
≤ 256
|
≤ 256
|
|
Maximum Transmit Power
|
29 dBm (combined power)
|
30 dBm (combined power)
|
|
MIMO: Spatial Streams
|
2 x 2:2
|
2 x 2:2
|
|
Radio Protocols
|
802.11a/b/g/n
|
802.11a/b/g/n
|
|
Highest Rate
|
600 Mbit/s
|
600 Mbit/s
|
