S5700-52X-LI-AC
-
Model:
S5700-52X-LI-AC 02354216 Huawei Quidway S5700 Switch -
Detail:
48 Ethernet 10/100/1000 ports, 4 10 Gig SFP+, AC 110/220V -
Price:
$1700.00
- Free Technical Support
- Product Quality Protection
- On-time Shipment
- +86 755 8215 3862
- leo@uonel.com
- ywx39894
Overview (S5700-52X-LI-AC)
Huawei S5700-52X-LI-AC is one of the S5700-LI Series Switches.The S5700-LI is a next-generation energy-saving gigabit Ethernet switch that provides flexible GE access ports and 10 GE uplink ports. Building on next-generation, high-performance hardware and the Huawei Versatile Routing Platform (VRP), the S5700-LI supports Advanced Hibernation Management (AHM), intelligent stack (iStack), flexible Ethernet networking, and diversified security control. It provides customers with a green, easy-to-manage, easy-to-expand, and cost-effective gigabit to the desktop solution. In addition, Huawei customizes specialized models to meet customer requirements to suit special scenarios. And the S5701-LI series with front power sockets can be installed in the 300 mm deep cabinet. They can be maintained through the front panel, saving space in small equipment rooms.
Quick Specs
Figure 1 shows the appearance of S5700-52X-LI-AC.
Table 1 shows the Quick Specs.
|
Product Code |
S5700-52X-LI-AC |
|
Fixed Interfaces |
48 x 10/100/1,000 Base-T Ethernet ports, 4 x 10 GE SFP+ ports |
|
Power Supply |
AC power supply, supporting RPS |
|
Forwarding Performance |
132 Mpps |
|
Switching Capacity |
256 Gbit/s |
|
Operating Environment |
Long-term operating temperature: 0°C to 50°C Relative humidity: 5% to 95% (non-condensing) |
|
Power Socket Position |
rear power sockets |
|
Memory (RAM) |
256 MB |
|
Flash |
200 MB |
|
Dimensions (W x D x H) |
442.0 mm x 310.0 mm x 43.6 mm (17.4 in. x 12.2 in. x 1.72 in.) |
|
Weight |
≤ 5 kg (11.02 lb) |
Product Details
Figure 2 shows the front panel of S5700-52X-LI-AC.
Note:
|
① |
Forty-eight 10/100/1000BASE-T ports |
|
② |
Four 10GE SFP+ ports |
|
③ |
One mini USB port |
|
④ |
One console port |
Figure 3 shows the back panel of S5700-52X-LI-AC.
Note:
|
① |
Ground screw |
|
② |
RPS socket |
|
③ |
Jack for AC terminal locking latch |
|
④ |
AC socket |
- The AC terminal locking latch is not delivered with the switch.
